| GUS107 |
 |
| GUS 107 is ultrasound NDT system that generates high-power tone burst ultrasound, and convert analog ultrasound signal to digital data for analysis and data processing. This system is configured of high-power ultrasound pulse/receiver board (2500W, 300V) and 50MHz analog to digital conversion board. Base system of GUS107 is Indu-strial PC embedded Pentium III CPU. User can connect switch box that has multiple Tx and Rx switches (GUS SW107) with GUS 107 for connection of multiple ultrasound probe. |
| Feature |
- Tone burst ultrasonic generation
- Control of Tx and Rx properties: Repetition rate, Pulse width, Freq., Gain, Amplitude
- Analog to Digital conversion: Max. 50MHz
- Data restoration and reviewing save data: RF-data (ASCII type)
|
|
|
|
|
|
